Rtd Isolator

RTD Type No

Input RTD

Output Range

UNI 811 31SOL PV0S1010

CU/10/PT25

0-10VDC

Any RTD input settable switch to output voltage 0-10VDC

UNI 811 31SOL PV0S2010

PT100/CU100/NI120

0-10VDC

UNI 811 31SOL PVXXX010

XXX

0-10VDC

UNI 811 31SOL PV0S1100

CU10/PT25

0-100mVDC

Any RTD input settable switch to output voltage 0-100mVDC

UNI 811 31SOL PV0S2100

PT100/CU100/NI120

0-100mVDC

UNI 811 31SOL PVXXX100

XXX

0-100mVDC

UNI 811 31SOL PIOS3420

PT500/NI500/NI604

4-20mA

Any RTD Input settable

Switch to output current 4-20mA

UNI 811 31SOL PIOS4420

PT1000/CU1000

4-20mA

UNI 811 31SOL PIXXX420

XXX

4-20mA

UNI 811 31SOL PIOS1020

CU10/PT25

0-20mA

Any RTD input settable switch to output current 0-20mA

UNI 811 31SOL PIOS2020

PT100/CU100/NI120

0-20mA

UNI 811 31SOL PIXXX020

XXX

0-20mA
