Multipole Connectors
Product Details:
X
Product Description
| Working Current Mx. | Working Voltage | Tse Voltage Ueff | Insulation Resist- ance | Insert Material | Conn- ection | Contacts Material | No of Poles |
| 16 A | 400 / 690 V | 3 KV | >10 10 | Thermo Plastic Resin | 1 | Copper alloy | 6,8,10, 16,24, 32,48 |
| 35 A | 600V | 3 kv | Thermo Plastic Resin | 2 | Copper alloy | 612 | |
| 10 A | 230/400V | 3 kv | Thermo Plastic Resin | 2 | Copper Alloy | 3,4 | |
| 10 A | 230 / 400V | 3 kv | Polyamide | 3 | Copper alloy | 7,15,25, 40,50 (2*25)64 80(2*40) 128 (2*64)+PE | |
| 16 A | 230/400V | 3 kv | Thermo- plastic Resin | 2 | Copper alloy | 10,16,32, 48,64 | |
| 80A 16 A | 400/690 V | 3 kv | Thermo- plastic Resin | 2 | Copper alloy | 42220 |
Enclosure - Different Versions & Technical Details
Series ICO C (Plastic version is also available)
Degree of Protection IP 44
Degree of Protection IP 44
| Enclosure Size | Cable Entry | Thread | Surface Mounting | Bulkhead Mounting | Panel Cut out mm | Thermo Plastic Cover | |
| Top | Side | ||||||
| 3 | Yes | PG 11 | Yes | Yes | 22 * 22 | Yes | |
| 4 | Yes | PG 11 | Yes | Yes | 22 * 22 | Yes | |
Series ICO A, ICO B, ICO E, ICO D
2 Lever
Degree of Protection IP 65
| Enclosure Size | Cable Top | Entry Side | Thread | Surface Mounting | Bulkhead Mounting | Panel Cut out mm | Thermo Plastic Cover |
| 8 | Yes | Yes | PG 11, PG 16 | Yes | Yes | 40 * 36 | Yes |
| 10 | Yes | Yes | PG 16 | Yes | Yes | 60 * 36 | Yes |
| 16 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 70 * 36 | Yes |
| 24 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 96 * 36 | Yes |
| 32 (16*2) | Yes | Yes | PG 29 | Yes | Yes | 86 * 71 | Yes |
| 4/8 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 96 * 36 | Yes |
Series ICO A, ICO B, ICO E, ICO D
1 Lever
Degree of Protection IP 65
| Enclosure Size | Cable Top | Entry Side | Thread | Surface Mounting | Bulkhead Mounting | Panel Cut out mm | Thermo Plastic Cover |
| 6 | Yes | Yes | PG 11, PG 16 | Yes | Yes | 48 * 35 | Yes |
| 10 | Yes | Yes | PG 16 | Yes | Yes | 60 * 36 | Yes |
| 12 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 86 * 71 | Yes |
| 16 | Yes | Yes | PG 16, PG 29 | Yes | Yes | 70 * 36 | Yes |
| 24 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 96 * 36 | Yes |
| 32 (16*2) | Yes | Yes | PG 29 | Yes | Yes | 86 * 71 | Yes |
| 48 (24*2) | Yes | Yes | Pg 29, PG 36 | Yes | Yes | 96 * 80 | Yes |
| 4/8 | Yes | Yes | PG 21, PG 29 | Yes | Yes | 96 * 36 | Yes |
Series ICO C, ICO CA, ICO D
1 Lever & 2 Lever
Degree of Protection IP
| Enclosure Size | Cable Top | Entry Side | Thread | Surface Mounting | Bulkhead Mounting | Panel Cut out mm | Thermo Plastic Cover |
| 10 | Yes | Yes | PG 16 | Yes | Yes | 57 * 24 | Yes |
| 16 | Yes | Yes | PG 16, PG 21 | Yes | Yes | 73 * 24 | Yes |
| 32 (16*2) | Yes | Yes | PG 21, PG 29 | Yes | Yes | 73 * 48 | Yes |
| 48 | Yes | Yes | Yes | Yes | Yes | ||
| 64 | Yes | Yes | Yes | Yes | Yes |
